Description
This LCD/LED fixed style wall mount bracket fits most 60 inch to 100inch LCD displays with a maximum VESA hole pattern of 900×600. Its simple construction allows for easy installation. It can be used in both residential and commercial environments.
|
Physical Characteristics
|
|
|---|---|
| Mounting Style | Fixed Wall Mount |
| Color | Black |
| Material | Steel, Plastic |
| Mounting Pattern | VESA 200×200, 300X200, 300X300, 400×200, 400X300, 400×400, 600×400,600×600 ,800×600, 900×600 |
| Screen Size | 60 – 100 inches [152.4 – 254cm] |
| Weight Capacity | 165 lbs [75kg] |
| Tilt | No |
| Profile | 30.5 mm |
| Bubble Level | Compliant |
| Installation | Solid Wall or Double Stud |
|
Approvals
|
|
| RoHS | Compliant |
| Reach | Compliant |
|
Packaging Information
|
|
| Package Quantity | 1 |
| Mounting Hardware | 4 – M5x14 Screws 4 – M6x14 Screws 4 – M6x30 Screws 4 – M8x30 Screws 4 – M8x50 Screws 4 – Rectangular Washers 8 – Small Spacers 8 – Big Spacers 6 – ST6.3×55 Screws 6 – Concrete Anchors 6 – D6 Washers |
| Product Weight | 7.75 lbs [3.5kg] |
