Description
Overview
These micro-adjustment brackets are ideal for video wall and other multi-screen installations.
 |
Ideal for Video Wall ApplicationsThese pairs of brackets are ideal for video wall and other multi-screen installations. Multi-Dimensional Micro AdjustmentThis allows precision alignment of the video wall configuration including depth, height and tilt.
|
Features
Installation
Specifications
|
Physical Characteristics
|
|
|---|---|
| Color | Durable Powder-Coated Black Finish |
| Material | Steel |
| Screen Size | 40 – 70 inches [101.6 – 177.8cm] |
| Dimensions | 42 x 472 x 79 mm [1.7 x 18.6 x 3.1 inches] |
| Fine Adjustment | 10/20mm [0.39/0.79 inches] |
| Tilt | -2° ~ +2° |
| Direction Indicator | Compliant |
|
Compatibility
|
|
| MT-1600-CP | Video Wall Ceiling Mount – Ceiling Plate |
| MT-1600-P1750 | Video Wall Ceiling Mount – Connecting Pole 1750mm |
| MT-1600-P2250 | Video Wall Ceiling Mount – Connecting Pole 2250mm |
| MT-1600-R700 | Video Wall Ceiling Mount/Stand – Mounting Rail 700mm |
| MT-1600-R1500 | Video Wall Ceiling Mount/Stand – Mounting Rail 1500mm |
| MT-1600-R2000 | Video Wall Ceiling Mount/Stand – Mounting Rail 2000mm |
| MT-1600-J | Video Wall Ceiling Mount – Joining Collar |
|
Approvals
|
|
| RoHS | Compliant |
| Reach | Compliant |
|
Packaging Information
|
|
| Package Quantity | 1 |
| Mounting Hardware | 4 – M5x14 Screws 4 – M6x14 Screws 4 – M6x30 Screws 4 – M8x20 Screws 4 – M8x30 Screws 4 – Rectangular Washers 8 – Small Spacers 4 – Big Spacers 6 – ST6.3×55 Screws 6 – Concrete Anchors 6 – D6 Washers |
| Product Weight | 6.6 lbs [3 kg] |
Reviews
There are no reviews yet.
